PF Series Plate & Frame Heat Exchangers

Taco PF Series Plate & Frame Heat Exchangers are designed, constructed and tested to ASME Section VIII, Div. 1 requirements. Computerized product selection helps you choose the heat exchanger that is just the right fit for your application requirements. Built to last, Taco PF Series Plate & Frame Heat Exchangers utilize .5MM thick plates for standard designs and .6MM plates for higher pressure design requirements. Taco PF models can be offered with single wall or double wall plates depending on your application requirements.

Contact your local Taco Rep for assistance with sizing.

Catalog
Instruction Sheet
Brochure
eLink Instructions
Introducing eLink® Connectivity

eLink® is Taco Comfort Solutions’ line of cloud services, providing users access to their devices data and performance while giving them control over their comfort. Using a Taco product featuring eLink provides users with support, monitoring, or controls straight from their mobile phone, tablet, or laptop. Now, it’s even easier to get important information, status updates and control of your Taco products. eLink provides the answer for both residential and commercial applications, just look for the logo to see if your product is connected.

Products featuring eLink are categorized into three application specific categories: Support, Monitoring, and Controls. These features of eLink identify how the cloud provides you with the support and control you require.

Learn More

Find your Taco Sales Representative
Click below to get in touch with your local Taco supplier:
Find a Rep
We’re Here to Help
Support is only a click away! Our dedicated customer service and tech support teams are waiting to hear from you.
Support
Performance Data
GPM: 50 – 7,000 in a single unit
Sizes: 6 x 18″ – 46 x 120″
Connection Sizes: 1 – 12″
Working Pressure: 150, 300PSI Standard
Max. Operating Temp: 230°F standard (Higher temperatures optional)
Features
  • Designed, constructed and tested to ASME section VIII, Div. 1 requirements
  • .5MM plate thickness on standard designs for increased durability
  • High degree of flexibility in materials to meet varying application requirements
  • Ability to design for future expansion
  • Movable pressure plate allows for cleaning without removing system piping
  • Available in single or double wall configuration
  • Insulated shroud and drip tray available as an option
  • All fabrication done in house
  • Computerized selections to ensure fast and easy design
  • National Board Registration
  • CRN Registration (Optional)
Applications
  • Economizer free cooling
  • Ground source heat pumps
  • Ground water cooling
  • Water source heat pump freeze protection isolation
  • Campus (district) heating and cooling
  • Industrial processes
  • Pressure zone isolation
  • Pool and Spa
