00R-IFC Radiant Heating Circulator

00R-IFC Radiant Heating Circulator

The 00R-IFC Radiant Heating Circulator is specifically designed for the flow and head requirements of the radiant heating systems you design and install today. This unit’s performance curve delivers flow you can use in a wide combination of tube diameters and lengths of run. Standard on the 00R-IFC Radiant Heating Circulator is a removable, spring-loaded Integral Flow Check (IFC®) that prevents gravity flow and eliminates the need for a separate, in-line check valve. Available in cast iron or stainless steel construction with IFC located in the discharge port  for easy access and service. Casing can be purged using standard piping configurations. 00R-IFC Radiant Heating Circulator also features an LED indicator light to show when pump is operating to assist with system diagnostics.

Catalog
Instruction Sheet
Submittal Data
Find your Taco Sales Representative
Click below to get in touch with your local Taco supplier:
Find a Rep
We’re Here to Help
Support is only a click away! Our dedicated customer service and tech support teams are waiting to hear from you.
Support
Performance Data

Flow Range: 0-12.5 GPM
Head Range: 0′ – 15′
HP: 1/25
Min. Fluid Temp.: 40°F. (4°C)
Max. Fluid Temp.: 230°F (110°C)
Max. Working Pressure: 125 PSI
Connection Sizes: ¾”, 1″, 1 ¼”, 1 ½” Flanged

Features
  • Specifically Designed for Radiant Heating Applications
  • Integral Flow Check (IFC)
    • Simplifies Piping
    • Prevents Gravity Flow/Reverse Flow
    • Eliminates Separate In-Line Flow Check
    • Reduces Installed Cost
    • Improves System Performance
  • LED Indicator Light
  • Unique Replaceable Cartridge Design – Field Serviceable
  • Compact Design
  • Quiet, Efficient Operation
  • Direct Drive-Low Power Consumption
  • Self-Lubricating
  • No Mechanical Seal
  • Unmatched Reliability — Maintenance Free
  • Available in Cast Iron or Stainless Steel Construction
Applications
  • Radiant Heating Systems
Case Studies

Low-Lead
Compliant
